Mission Magnum 2500 MCM250 style Centrifugal Pump


BETTER offers a complete line of centrifugal sand pumps, sizes range from 3x2 to 10x8;


Bare pumps, horizontal packages, vertical packages, overhead belt driven configurations are available, starters are optional;


Explosion-proof electric motors are available up to 200HP in 1200, 1500, 1800, 2400, 3600 RPM;


To transfer the drilling fluid in the solid control system, feeding desander, desilter, shale shaker and centrifuge, or to match with mud hopper for mud mixer, or as charging pump of mud pump, playing an important role;


Completely identical size with those brand pumps in the markets; 100% interchangeable spare parts;


Mechanical seal and packing seals are both available.


BETTER Mission Magnum style Centrifugal Pump-Open Impeller


It has an open impeller design that contains wide-tipped vanes and a more tangential circumference of the suction allowing the pump to create a smoother flow pattern when handling abrasive fluids. It is available in hard ductile iron, high chrome alloy fluid ends. The pumps can be unitized with electric motors, diesel engines, and hydraulic motors (horizontal, vertical, or close-coupled configuration). Sizes from 3x2x13 to 10x8x14.


BETTER MCM 250 style Centrifugal Pump-Semi Open Impeller


It has a semi-open impeller design that contains wide-tipped vanes and a more tangential circumference of the suction allowing the pump to create a smoother flow pattern when handling abrasive fluids.Sizes from 3x2x13 to 10x8x14.


BETTER Mission Sandmaster style Centrifugal Pump-Short Frame


It has more compact design and can be adapted for hydraulic motor drive. These features make it ideal for use in application such as oilfield frac truck, cementing, charge pump for water well drilling. The frame and shaft has been shorten 4” to compare with the general series. It is a choice when space is a premium and prime mover options and limited. Sizes from 3x2x13 to 10x8x14.


BETTER Mission Spacesaver style Centrifugal Pump – Close Coupled


It has a very small foot print for applications where space is a premium. These heavy duty pumps require minimum mounting space and are close-coupled, eliminating couplings and coupling alignment considerations. Sizes from 1x1½ to 3x4.


BETTER Mission XP style Centrifugal Pump - Large Volume


It is ideally suited for pumping high volumes of heavy slurries that are abrasive, corrosive. An excellent choice for high volume mobile and stationary applications where a small footprint is critical. Sizes 8X6X18, 12x10x23


BETTER Mission Magnum Vertical style Centrifugal Pump


The Vertical centrifugal pump provides the good solution for those small space on the floor. Common applications include Mud Pumping-offshore/onshore, Solids Control, and Dredging.


BETTER High Efficiency Mission Style Shear Pump


Horizontal centrifugal pump structure, belt driven for high speed work; Stainless steel turbine and shear plate to ensure the continuous shear force;To improve bentonite particles hydration degree, reduces the bentonite clay need by 30%.


Pump Spare Parts


All BETTER pumps are built using the excellent quality components, and its parts are 100% identical in all dimensions to Mission, Halco, SPD Baker Mud Hog, MCM 250 series, Mattco, Harrisburg, and etc. Including casing assy., impeller(open & semi-open), stuffing box, wear pad, mechanical seal, shaft, shaft sleeve, shaft packing, power end gaskets, fluid end gaskets, oil seal kits, inboard bearing, outboard bearing, bearing covers, housing, etc.


Please contact our sales if you are interested in any of our products.


Sales Manager


Att.: Anna


BETTER Drilling Fluid Equipment Industrial Limited


http://www.drillingfluidequip.com


info[a]drillingfluidequip.com


Skype: betterdrilling2008


MSN: better_china [a] hotmail.com
